Walk-in Refrigeration Walk In Coolers Dade CI-687.7-R 6'X8'X7.7" Quick Ship Indoor Walk-In Cooler with Floor, Remote Dade CI-687.7-R 6'X8'X7.7" Quick Ship Indoor Walk-In Cooler with Floor, Remote
Dade Refrigeration Solutions, Quick Ship Walk-Ins
General Description::
The construction of walk-in facilities will utilize pre-made, meticulously crafted modular panels designed for swift and precise on-site assembly. These panels adhere to the overarching construction specifications and General Design Information reference material.
In accordance with DOE regulations, both panels and doors are purpose-built and certified for use within walk-in cooler and freezer applications.
Insulation: The insulation used comprises 4-inch thick XPS insulation. The R-values for these 4-inch panels are as follows:
Coolers R-29
Freezers R-32
All Quick Ship units come with floors
Metal Coatings:
The interior and exterior surfaces of walk-in coolers and freezers are clad in 26-gauge acrylic-coated stucco galvanized steel. The inner floor boasts an .080 textured aluminum finish. The floor panels are engineered to support a stationary load of 700 lbs. per square foot with even distribution.
Entrance Door:
Standard walk-ins come equipped with one flush-mount self-closing entrance door. Measure 36" x 78". Their energy consumption rates (kWh/day) are as follows:
Coolers: 2.77
Freezers: 7.79 The entrance door includes the following features:
Adjustable backing plate for each hinge, facilitating in-field hinge adjustment
Two spring-loaded cam-lift hinges
Hydraulic door closure
Deadbolt-locking handle
Pre-wired compact fluorescent vapor-proof light fixture
Interior safety release
Magnetic gaskets along the top and both sides
An adjustable double vinyl wiper gasket along the bottom
Drip guard for outdoor models
Refrigeration System:
Every unit comes complete with either a Self-Contained or Remote Refrigeration System.
Warranty:
The units come with an 50 year thermal insulation warranty. Extended four-year compressor warranty optional. Panels are covered under warranty for 15 years. Doors and Floors come with 5 year warranty
From The Manufacturer
6'x8'x7.7"remote indoor walk-in cooler w/floor, 30" door, 115v-60-1ph, 360 cu ft., 95°F ambient temp.
